ASUS Prime X299-A II ATX Motherboard | LGA2066 | 8x DDR4 Slots
KEY FEATURES
- Intel LGA 2066 socket: Ready for the latest Intel® Core™ X-series processors
- AI Overclocking: Quickly optimizes your CPU performance based on the CPU and cooler, achieving results that are extremely close to manual tuning by experts
- Robust power design: 12 IR3555 power stages, ProCool II connectors, alloy chokes and ultra-durable capacitors for stable power delivery
- M.2 heatsink: Ultra-efficient heatsink reduces M.2 SSD temperatures by up to 20° C for unthrottled transfer speeds and enhanced reliability
- Next-gen connectivity: Intel Optane memory ready, Intel® VROC support, dual M.2 support, and USB 3.2 Gen Type-C™
100% Safe & Secure Checkout
Reviews
Frequently Asked Questions
What processors are compatible with the ASUS Prime X299-A II?
How many memory slots does the ASUS Prime X299-A II have?
Can I use multiple GPUs with the ASUS Prime X299-A II?
ASUS Prime X299-A II ATX Motherboard | LGA2066 | 8x DDR4 Slots
Description
The ASUS Prime X299-A II brings Intel's high-end X299 platform to ATX form factor, built around the LGA2066 socket for Intel Core X-series processors. This is a serious enthusiast platform designed for content creators, workstation users, and power users who need the multi-core performance and expanded memory capacity that only the X299 chipset can deliver. With support for up to 256GB of DDR4 memory across eight DIMM slots, it offers the kind of memory expandability that mainstream platforms simply can't match.
The board supports DDR4 speeds from 2133MHz up to 4266MHz with compatible modules, giving you flexibility to balance performance and budget. Three M.2 slots provide ample storage expansion options, while eight SATA ports ensure plenty of room for traditional drives. The dual PCIe x16 slots handle multi-GPU setups, and two additional PCIe x1 slots add room for expansion cards. Gigabit Ethernet and Realtek S1220A audio codec handle networking and sound duties.
ASUS includes essential accessories in the box: an I/O shield, SATA cables for storage connections, M.2 mounting hardware, and a comprehensive user guide to help with setup. The board supports XMP memory profiles for easy overclocking of compatible DDR4 modules. While the X299 platform targets users with specific high-performance needs rather than general gaming builds, it delivers the processing power and memory capacity that demanding applications require.
Feature
Easy 14 days Returns
Eligible for Next day Delivery
100% Money-back guarantee
Reliable Customer Support
Secure payment method
Shipping Information
- Next Business Day: £6.99
- 2 days Delivery: £4.99
- 3- 5 Days Shipping: £3.99
- Orders Over £99.00: Free Standard Delivery
| Processor | |
|---|---|
| Processor manufacturer | Intel |
| Processor socket | LGA 2066 (Socket R4) |
| Compatible processor series | Intel® Core™ X-series |
| Maximum number of SMP processors | 1 |
| Supported processor sockets | LGA 2066 |
| Memory | |
|---|---|
| Supported memory types | DDR4-SDRAM |
| Number of memory slots | 8 |
| Memory slots type | DIMM |
| ECC сompatibility | Non-ECC |
| Supported memory clock speeds | 2133,2400,2666,2800,2933,3000,3200,3300,3333,3400,3466,3600,3733,3800,3866,4000,4133,4266 MHz |
| Maximum internal memory | 256 GB |
| Unbuffered memory | Yes |
| Storage controllers | |
|---|---|
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, SATA III |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 10 |
| Graphics | |
|---|---|
| Parallel processing technology support | 2-Way SLI, 3-Way CrossFireX, 3-Way SLI, Quad-GPU CrossFireX, Quad-GPU SLI |
| On-board graphics card | No |
| Internal I/O | |
|---|---|
| USB 2.0 connectors | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
| Number of SATA III connectors | 8 |
| Front panel audio connector | Yes |
| Front panel connector | Yes |
| ATX Power connector (24-pin) | Yes |
| Number of EATX power connectors | 2 |
| CPU fan connector | Yes |
| Number of chassis fan connectors | 2 |
| Thunderbolt headers | 1 |
| Number of COM connectors | 1 |
| Rear panel I/O ports | |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| PS/2 ports quantity | 1 |
| Headphone outputs | 1 |
| Microphone in | Yes |
| S/PDIF out port | Yes |
| Network | |
|---|---|
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| LAN controller | Intel® I219-V |
| Wi-Fi | No |
| Features | |
|---|---|
| Component for | PC |
| Motherboard form factor | ATX |
| Motherboard chipset family | Intel |
| Motherboard chipset | Intel® X299 |
| Audio chip | Realtek ALC S1220A |
| Audio output channels | 7.1 channels |
| Product colour | Black, Silver |
| Power source type | ATX |
| Cooling type | Passive |
| Windows operating systems supported | Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64, Windows 10 x64 |
| Harmonized System (HS) code | 84733020 |
| Expansion slots | |
|---|---|
| PCI Express x1 (Gen 3.x) slots | 2 |
| PCI Express x16 (Gen 3.x) slots | 3 |
| Number of M.2 (M) slots | 3 |
| BIOS | |
|---|---|
| BIOS type | UEFI AMI |
| BIOS memory size | 128 Mbit |
| ACPI version | 6.1 |
| System Management BIOS (SMBIOS) version | 3.1 |
| Processor special features | |
|---|---|
| Intel Extreme Memory Profile (XMP) | Yes |
| Intel® Optane™ Memory Ready | Yes |
| Weight & dimensions | |
|---|---|
| Width | 305 mm |
| Depth | 244 mm |
| Packaging content | |
|---|---|
| Drivers included | Yes |
| Other features | |
|---|---|
| HDD size | 2.5/3.5" |
| Processor lithography | 14 nm |
| Utilities included | Yes |
