MSI MPG B860I EDGE TI WIFI Mini-ITX Motherboard | LGA1851 | 2x DDR5 Slots | Wi-Fi 7
KEY FEATURES
- Intel LGA 1851 (Socket V1) Intel Core Ultra (Series 2)
- PC mini ITX Intel B860 7.1 channels
- DDR5-SDRAM 2 DIMM Maximum internal memory: 128 GB
- HDD & SSD M.2, SATA RAID support
- Clear CMOS button
- 5 Gigabit Ethernet Wi-Fi Wi-Fi 7 (802.11be) Bluetooth 5.4
100% Safe & Secure Checkout
Reviews
Frequently Asked Questions
MSI MPG B860I EDGE TI WIFI Mini-ITX Motherboard | LGA1851 | 2x DDR5 Slots | Wi-Fi 7
Description
The MSI MPG B860I EDGE TI WIFI brings high-end features to a Mini-ITX build, designed around Intel's new LGA1851 socket for Core Ultra Series 2 processors. This white-themed board stands out with premium connectivity including Thunderbolt 4 and Wi-Fi 7, making it ideal for compact workstations and small form factor gaming builds that don't compromise on performance or future-proofing. The B860 chipset strikes a balance between capability and cost, offering enthusiast features without the premium price of Z-series boards.
Memory support extends to 128GB of DDR5 across two DIMM slots, while storage gets serious attention with two M.2 slots - one PCIe 5.0 and one PCIe 4.0 for maximum flexibility. The single PCIe 5.0 x16 slot handles modern graphics cards with full bandwidth, and dual SATA 6Gb/s ports provide additional storage options despite the compact footprint. Display outputs include HDMI and USB-C DisplayPort, covering both traditional monitors and newer USB-C displays without needing a discrete GPU for basic tasks.
Setup benefits from included mounting screws and a Wi-Fi antenna, plus RGB LED pin headers for custom lighting integration. The board's white PCB and components create a clean aesthetic that works well in windowed Mini-ITX cases. Thunderbolt 4 support enables high-speed external storage and docking stations, while Wi-Fi 7 and Bluetooth 5.4 handle wireless connectivity with the latest standards. This combination of cutting-edge I/O and compact design makes it particularly suited to creators and professionals who need workstation-class connectivity in minimal space.
Feature
Easy 14 days Returns
Eligible for Next day Delivery
100% Money-back guarantee
Reliable Customer Support
Secure payment method
Shipping Information
- Next Business Day: £6.99
- 2 days Delivery: £4.99
- 3- 5 Days Shipping: £3.99
- Orders Over £99.00: Free Standard Delivery
| Processor | |
|---|---|
| Processor manufacturer | Intel |
| Processor socket | LGA 1851 (Socket V1) |
| Compatible processor series | Intel Core Ultra (Series 2) |
| Memory | |
|---|---|
| Supported memory types | DDR5-SDRAM |
| Number of memory slots | 2 |
| Memory slots type | DIMM |
| Memory channels | Dual-channel |
| ECC сompatibility | Non-ECC |
| Maximum internal memory | 128 GB |
| Unbuffered memory | Yes |
| Storage controllers | |
|---|---|
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, SATA |
| RAID support | Yes |
| RAID levels | 0, 1 |
| Graphics | |
|---|---|
| On-board graphics card | No |
| Internal I/O | |
|---|---|
| USB 2.0 connectors | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
| Number of SATA III connectors | 2 |
| S/PDIF out connector | Yes |
| Audio connector | Yes |
| Front panel connector | Yes |
| Power fan connector | Yes |
| CPU fan connector | Yes |
| Number of CPU fan connectors | 1 |
| Chassis intrusion connector | Yes |
| TPM connector | Yes |
| RGB LED pin header | Yes |
| Rear panel I/O ports | |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 7 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Microphone in | Yes |
| Thunderbolt ports quantity | 1 |
| Network | |
|---|---|
| Ethernet LAN | Yes |
| Ethernet interface type | 5 Gigabit Ethernet |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 7 (802.11be) |
| WLAN controller model | Killer Wi-Fi BE1750x |
| Bluetooth | Yes |
| Bluetooth version | 5.4 |
| Features | |
|---|---|
| Component for | PC |
| Motherboard form factor | mini ITX |
| Motherboard chipset family | Intel |
| Motherboard chipset | Intel B860 |
| Audio output channels | 7.1 channels |
| Product colour | White |
| Power source type | ATX |
| Expansion slots | |
|---|---|
| PCI Express x16 (Gen 4.x) slots | 1 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| Number of M.2 (M) slots | 2 |
| 1st M.2 highest PCI Express generation | 5.0 |
| 2nd M.2 highest PCI Express generation | 4.0 |
| BIOS | |
|---|---|
| Clear CMOS button | Yes |
| Weight & dimensions | |
|---|---|
| Width | 170 mm |
| Depth | 170 mm |
| Packaging content | |
|---|---|
| Antenna included | Yes |
| Screws included | Yes |
| Cables included | SATA |
