MSI PRO H610M-E DDR4 mATX Motherboard | LGA1700 | 2x DDR4 Slots
KEY FEATURES
- Supports 12th Gen IntelĀ® Coreā¢, PentiumĀ® Gold and CeleronĀ® processors for LGA 1700 socket
- Supports DDR4 Memory, up to 3200(MAX) MHz
- Core Boost : With premium layout and digital power design to support more cores and provide better performance
- Memory Boost: Advanced technology to deliver pure data signals for the best performance, stability and compatibility
- Lightning Fast Experience: PCIe 4.0
- Audio Boost: Reward your ears with studio grade sound quality
- Steel Armor: Protecting VGA cards against bending and EMI for better performance, stability and strength
100% Safe & Secure Checkout
Reviews
Frequently Asked Questions
What processors are compatible with the MSI PRO H610M-E?
How much memory can the motherboard support?
What cooling features does the motherboard offer?
MSI PRO H610M-E DDR4 mATX Motherboard | LGA1700 | 2x DDR4 Slots
Description
This MSI PRO H610M-E DDR4 is a budget-focused micro ATX motherboard built around Intel's H610 chipset for LGA1700 processors. Supporting Intel Core i9, i7, i5, and i3 12th and 13th generation CPUs, it provides essential connectivity and features for straightforward home and office builds without unnecessary extras. The compact micro ATX form factor makes it suitable for smaller cases while still offering room for standard components.
Memory support centers on DDR4 with two DIMM slots accommodating up to 64GB total capacity. The board handles DDR4 speeds from 2133MHz up to 3200MHz, with higher speeds requiring compatible memory modules and CPU support. For display output, integrated graphics connect through VGA and HDMI ports, covering both legacy and modern monitor connections. The H610 chipset keeps things simple with basic expansion options focused on core functionality rather than enthusiast features.
This motherboard ships with the standard package including an I/O shield and user documentation to get your system running. The H610 chipset lacks advanced overclocking features but supports Intel's memory profiles for straightforward DDR4 speed configuration. MSI has positioned this as a reliable foundation for budget-conscious builders who need solid performance from Intel's latest processor generations without paying for premium features they won't use.
Feature
Easy 14 days Returns
Eligible for Next day Delivery
100% Money-back guarantee
Reliable Customer Support
Secure payment method
Shipping Information
- Next Business Day:Ā Ā£6.99
- 2 days Delivery: Ā£4.99
- 3- 5 Days Shipping: Ā£3.99
- Orders Over Ā£99.00: Free Standard Delivery
| Processor | |
|---|---|
| Processor manufacturer | Intel |
| Processor socket | LGA 1700 |
| Compatible processor series | IntelĀ® Coreā¢ i9 |
| Maximum number of SMP processors | 1 |
| Supported processor sockets | LGA 1700 |
| Memory | |
|---|---|
| Supported memory types | DDR4-SDRAM |
| Number of memory slots | 2 |
| Memory slots type | DIMM |
| Memory channels | Dual-channel |
| Supported memory clock speeds | 2133,2666,2933,3000,3200 MHz |
| Supported memory clock speed (max) | 3200 MHz |
| Maximum internal memory | 64 GB |
| Storage controllers | |
|---|---|
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, SATA III |
| Graphics | |
|---|---|
| Parallel processing technology support | Not supported |
| Internal I/O | |
|---|---|
| USB 2.0 connectors | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
| Number of SATA III connectors | 4 |
| Front panel audio connector | Yes |
| ATX Power connector (24-pin) | Yes |
| CPU fan connector | Yes |
| Number of chassis fan connectors | 1 |
| 12V power connector | Yes |
| TPM connector | Yes |
| Rear panel I/O ports | |
|---|---|
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Network | |
|---|---|
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Wi-Fi | No |
| Features | |
|---|---|
| Component for | PC |
| Motherboard form factor | micro ATX |
| Motherboard chipset family | Intel |
| Motherboard chipset | Intel H610 |
| Audio chip | Realtek ALC897 |
| Audio output channels | 7.1 channels |
| BIOS | |
|---|---|
| BIOS type | UEFI AMI |
| BIOS memory size | 256 Mbit |
| Clear CMOS jumper | Yes |
| System Management BIOS (SMBIOS) version | 3.4 |
| Weight & dimensions | |
|---|---|
| Height | 65 mm |
| Packaging content | |
|---|---|
| Cables included | SATA |
| Drivers included | Yes |
| Other features | |
|---|---|
| Weight | 760 g |
