Zyxel

Zyxel XS3800-28 Managed L2+ 10G Ethernet (100/1000/10000) Black

Name: Zyxel XS3800-28 Managed L2+ 10G Ethernet (100/1000/10000) Black
Brand: Zyxel
SKU: XS3800-28-ZZ0101F
Price: 3553.82 GBP
Availability: InStock

SKU: XS3800-28-ZZ0101F

£3,553.82

Quantity select

5 in stock. Need more? Contact us!

FREE carbon neutral delivery on orders over £59

Description

4 x RJ-45, 8 x Multi-Gigabit combo RJ-45 / SFP+, 16 x SFP+, 560 Gbps, 416 Mpps, 64 MB/8 GB Flash/RAM, 100 - 240 V AC, 50/60 Hz, 441 x 360 x 44 mm

Zyxel...

Delivery & Returns

Got questions? Call our team on 020 8208 1234

£3,553.82

Quantity

Quantity select

Description

4 x RJ-45, 8 x Multi-Gigabit combo RJ-45 / SFP+, 16 x SFP+, 560 Gbps, 416 Mpps, 64 MB/8 GB Flash/RAM, 100 - 240 V AC, 50/60 Hz, 441 x 360 x 44 mm

Zyxel XS3800-28. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000), Basic switching RJ-45 Ethernet ports quantity: 4. MAC address table: 32 entries, Switching capacity: 560 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE.... Power connector: AC-in jack. Rack mounting

Flexible port design XS3800-28 offers a maximum of 24 10G fiber ports or 12 10G copper ports that are for most flexible adoption to your networks. Essentials of a core switch XS3800-28 is suitable for network aggregation such as SMB or campus networks that require low latency and high-density 10G backbone architectures with basic routing capability. Restore Button The "Restore" button saves the last workable configuration as the custom default, which allows you to fall back instantly in case of network misconfigurations. Dual Power Two PSUs support active-standby power redundancy that triggers backup power supply if the main unit fails. Designed for the long haul Quality hardware design is how Zyxel differentiate ourselves from others. We ensure stability and longevity for XS3800-28 for your networks.

View Product Specifications

Reviews

Frequently Asked Questions

When will it arrive?

Any order over £59 wil be shipped on our free 2-3 working day service, if you opt for Next Working Day shipping then this will be with you the next working day between 09:00 and 18:00. Deliveries to Northern Ireland, Channel Islands and the Scottish Highlands will be on a 3 day service.

What information do I need to provide for the delivery?

How long is the returns policy?

Delivery & Returns

How long will it take to receive my order?

We provide multiple shipping options for our customers including next day delivery. If you opt for Next Working Day shipping order needs to be placed before 2 PM; all orders placed after 2pm will be processed following working day and then this will be with you the next working day between 09:00 and 18:00. Deliveries to Northern Ireland, Channel Islands and the Scottish Highlands will be on a 3 working day service.

Can I choose a specific day to receive my order?

This is something that we are working hard to bring to you - we recognise that having deliveries on preferred days not only makes it easier for you but it is also great for the environment. By having deliveries arranged on days that you are going to be in or consolidating your orders to arrive to you at the same time means that the courier won't need to come back multiple times due to missed deliveries or multiple deliveries.

Can I change my delivery address once the order has been placed?

Our systems are highly automated, where possible we will do our utmost to accommodate this. To ensure we maintain a high delivery success rate most of our orders are picked and prepped for shipment within 30 minutes

How do I return my order?

If you need to return your order please raise a return through your order page detailing the reason for return. Once this form has been submitted it will be reviewed by the Returns Department who will contact you to arrange the return.
Please note the returns department may ask for more information such as the serial number(s) and images where applicable to process the return.

How long do I have to return an item?

For most products bought online, you have a legal right to change your mind within 14 days and receive a refund. If you wish to return unwanted products, you must let us know that you want to return them within 14 calendar days from the day after delivery. The item must also be returned to us within 7 working days from approval of return and receipt of the return label

Are returns free?

Returns for faulty / damaged items will be free of charge
Returns for unwanted items that have no fault will incur a minimal returns fee - delivery charges will not be refunded

Expert Advice Carbon Neutral Deliveries Free 3 Day Delivery Over £59

Management features
MIB support	Y
Configuring Location Settings (CLI)	Y
Traffic shaping	Y
Traffic classification	Y
ARP inspection	Y
Web-based management	Y
Quality of Service (QoS) support	Y
Switch layer	L2+
Switch type	Managed

Ports & interfaces
Power connector	AC-in jack
Fiber optic connector	SFP+
SFP+ module slots quantity	16
Combo SFP ports quantity	8
Basic switching RJ-45 Ethernet ports type	10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity	4

Network
VLAN support	Y
Flow control support	Y
Broadcast storm control	Y
Rate limiting	Y
Auto-negotiation	Y
Spanning tree protocol	Y
Policy-based routing	Y
IP routing	Y
Port mirroring	Y
Copper ethernet cabling technology	10GBASE-T, 100BASE-T, 1000BASE-T
10G support	Y
Networking standards	IEEE 802.1D, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3ah, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3x, IEEE 802.3z

Optical fiber
Fiber ethernet cabling technology	1000BASE-X

Data transmission
Packet buffer memory	4 MB
Forwarding rate	416 Mpps
Switching capacity	560 Gbit/s
MAC address table	32 entries

Security
Password protection	Y
Loop protection	Y
BPDU filtering/protection	Y
Authentication	MAC-based authentication
MAC address filtering	Y
SSH/SSL support	Y
IGMP proxy	Y
IGMP snooping	Y
Access Control List (ACL)	Y
DHCP features	DHCP client, DHCP relay, DHCP server

Multicast features
Multicast support	Y

Design
Reset button	Y
Product colour	Black
Rack mounting	Y

Performance
Harmonized System (HS) code	85176990
Mean time between failures (MTBF)	656274.78 h
Flash memory	64 MB
Internal memory	8000 MB

Power
AC input frequency	50 - 60 Hz
AC input voltage	100 - 240 V
Number of power supply units	2
Redundant power supply (RPS) support	Y
Power supply included	Y

Power over Ethernet (PoE)
Power over Ethernet (PoE)	N

Operational conditions
Storage relative humidity (H-H)	10 - 95%
Operating relative humidity (H-H)	10 - 95%
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight & dimensions
Weight	4.81 kg
Height	44 mm
Depth	340 mm
Width	441 mm

Packaging data
Rack mount kit	Y
Cables included	AC

Management features
MIB support	Y
Configuring Location Settings (CLI)	Y
Traffic shaping	Y
Traffic classification	Y
ARP inspection	Y
Web-based management	Y
Quality of Service (QoS) support	Y
Switch layer	L2+
Switch type	Managed

Ports & interfaces
Power connector	AC-in jack
Fiber optic connector	SFP+
SFP+ module slots quantity	16
Combo SFP ports quantity	8
Basic switching RJ-45 Ethernet ports type	10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity	4

Network
VLAN support	Y
Flow control support	Y
Broadcast storm control	Y
Rate limiting	Y
Auto-negotiation	Y
Spanning tree protocol	Y
Policy-based routing	Y
IP routing	Y
Port mirroring	Y
Copper ethernet cabling technology	10GBASE-T, 100BASE-T, 1000BASE-T
10G support	Y
Networking standards	IEEE 802.1D, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3ah, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3x, IEEE 802.3z

Security
Password protection	Y
Loop protection	Y
BPDU filtering/protection	Y
Authentication	MAC-based authentication
MAC address filtering	Y
SSH/SSL support	Y
IGMP proxy	Y
IGMP snooping	Y
Access Control List (ACL)	Y
DHCP features	DHCP client, DHCP relay, DHCP server

Operational conditions
Storage relative humidity (H-H)	10 - 95%
Operating relative humidity (H-H)	10 - 95%
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
