Gigabyte A520I AC mini ITX AMD Motherboard | AM4 Socket - 2 x DDR4 Memory Slots
KEY FEATURES
- Supports AMD Ryzen 5000 Series/ Ryzen 5000 G-Series/ Ryzen 4000 G-Series and Ryzen 3000 and Ryzen 3000 G-Series Processors
- Dual Channel ECC/ Non-ECC Unbuffered DDR4, 2 DIMMs
- Direct 6 Phases Digital VRM Solution with 55A DrMOS
- Ultra-Fast NVMe PCIe 3.0 x4 M.2
- Onboard Dual Band 802.11ac WIFI & BT 4.2 with Ultra Durable Antenna
- Realtek GbE LAN with Bandwidth Management
- DisplayPort, Dual HDMI for for Multiple Display
- RGB FUSION 2.0 with Addressable LED & RGB LED Strips Support
- Smart Fan 5 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
- Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card
- Anti-Sulfur Resistors Design
100% Safe & Secure Checkout
Reviews
Frequently Asked Questions
What processors are compatible with the Gigabyte A520I AC?
How much memory can the A520I AC support?
Does the A520I AC have built-in Wi-Fi?
Gigabyte A520I AC mini ITX AMD Motherboard | AM4 Socket - 2 x DDR4 Memory Slots
Description
The Gigabyte A520I AC mini ITX AMD Motherboard is a powerhouse designed for enthusiasts who demand high performance and reliability from their PC builds. With its compact form factor and advanced features, this motherboard is perfect for creating a powerful yet space-efficient system. Whether you're gaming, streaming, or multitasking, the A520I AC is engineered to deliver exceptional performance, making it an ideal choice for your next build.
Key Benefits
- Direct 6 Phases Digital VRM Solution: Experience incredible precision in power delivery with a digital PWM controller and DrMOS, ensuring your 3rd Gen AMD Ryzen™ processors perform at their best.
- Dual Band 802.11ac Wi-Fi & Bluetooth 4.2: Enjoy faster wireless connectivity with speeds up to 433 Mbps, allowing for seamless online gaming and streaming.
- Realtek 8118 Gaming LAN: Automatic bandwidth allocation prioritises your gaming applications, ensuring smooth and lag-free online experiences.
- Dual HDMI 2.1 Support: Connect multiple displays with 4K resolution at 60Hz, perfect for immersive gaming and multitasking.
- Smart Fan 5 Technology: Keep your system cool with advanced fan controls and temperature sensors that allow for customisable cooling solutions.
- RGB Fusion 2.0: Personalise your build with vibrant RGB lighting effects, easily controlled via the intuitive software interface.
Addtional Features
The Gigabyte A520I AC motherboard is packed with features that enhance both performance and usability. It supports up to 64 GB of DDR4 memory across two DIMM slots, ensuring ample capacity for demanding applications. The motherboard's NVMe PCIe Gen3 x4 M.2 connector allows for lightning-fast storage solutions, maximising your system's potential.
With a robust design that includes all-solid capacitors and a solid pin CPU power connector, the A520I AC ensures stable power delivery even under heavy loads. The motherboard also features advanced static-electricity and surge protection, safeguarding your components from potential damage.
For those who appreciate aesthetics, the motherboard's sleek black design is complemented by the RGB Fusion 2.0 technology, allowing you to create a visually stunning setup. The GIGABYTE APP CENTER provides easy access to all utilities and drivers, ensuring your system is always up to date.
Why Buy
The Gigabyte Gigabyte A520I AC mini ITX AMD Motherboard is not just a component; it's the foundation of a high-performance PC. With its combination of cutting-edge technology, user-friendly features, and robust design, this motherboard is tailored for gamers and PC builders who seek reliability and performance. Elevate your computing experience with the A520I AC and unlock the full potential of your system.
Feature
Easy 14 days Returns
Eligible for Next day Delivery
100% Money-back guarantee
24/7 Customer support
Secure payment method
Shipping Information
- Next Business Day: £6.99
- 2 days Delivery: £4.99
- 3- 5 Days Shipping: £3.99
- Orders Over £99.00: Free Standard Delivery
| Processor | |
|---|---|
| Maximum internal memory supported by processor | 64 GB |
| Supported processor sockets | Socket AM4 |
| Compatible processor series | AMD Ryzen 3000 Series |
| Processor socket | Socket AM4 |
| Processor manufacturer | AMD |
| Memory | |
|---|---|
| Unbuffered memory | Yes |
| Maximum internal memory | 64 GB |
| Supported memory module capacities | 1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 32GB |
| Supported memory clock speed (max) | 5300 MHz |
| Supported memory clock speeds | 2133,2400,2667,2933,3200,3333,3600,4000,4400,4600,4866,5000,5100,5200 MHz |
| ECC сompatibility | ECC & Non-ECC |
| Memory channels | Dual-channel |
| Memory slots type | DIMM |
| Number of memory slots | 2 |
| Supported memory types | DDR4-SDRAM |
| Storage controllers | |
|---|---|
| RAID levels | 0, 1, 10 |
| RAID support | Yes |
| Number of HDDs supported | 4 |
| Number of storage drives supported | 5 |
| Supported storage drive interfaces | M.2, SATA III |
| Graphics | |
|---|---|
| Number of displays supported | 3 |
| DirectX version | 12.0 |
| HDCP | Yes |
| Maximum resolution | 5120 x 2880 pixels |
| On-board graphics card | No |
| Parallel processing technology support | Not supported |
| Internal I/O | |
|---|---|
| RGB LED pin header | Yes |
| TPM connector | Yes |
| Serial port headers | 1 |
| EPS power connector (8-pin) | Yes |
| CPU fan connector | Yes |
| Power fan connector | Yes |
| ATX Power connector (24-pin) | Yes |
| Front panel connector | Yes |
| Front panel audio connector | Yes |
| Audio connector | Yes |
| Total number of SATA connectors | 4 |
| Number of SATA III connectors | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| USB 2.0 connectors | 1 |
| Rear panel I/O ports | |
|---|---|
| WiFi-AP antenna jack | 2 |
| Headphone outputs | 3 |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 1 |
| HDMI version | 2.1 |
| HDMI ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 2.0 ports quantity | 2 |
| Network | |
|---|---|
| Bluetooth version | 4.2 |
| Bluetooth | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Features | |
|---|---|
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| PC health monitoring | Fan, Temperature, Voltage |
| Product colour | Black |
| Audio output channels | 7.1 channels |
| Audio chip | Realtek ALC887 |
| Motherboard chipset | AMD A520 |
| Motherboard chipset family | AMD |
| Motherboard form factor | mini ITX |
| Component for | PC |
| Expansion slots | |
|---|---|
| Number of M.2 (M) slots | 1 |
| PCI Express x16 slots | 1 |
| BIOS | |
|---|---|
| Desktop Management Interface (DMI) version | 2.7 |
| System Management BIOS (SMBIOS) version | 2.7 |
| Clear CMOS jumper | Yes |
| ACPI version | 5.0 |
| BIOS memory size | 128 Mbit |
| BIOS type | UEFI AMI |
| Packaging data | |
|---|---|
| Package weight | 800 g |
| Package height | 78 mm |
| Package depth | 189 mm |
| Package width | 222 mm |
| Battery | |
|---|---|
| Battery type | CR2032 |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| Number of battery cells | 1 |
| Battery weight | 3 g |
| Lithium weight per battery | 0.07 g |
| Logistics data | |
|---|---|
| Country of origin | China |
| Products per shipping (inner) case | 1 pc(s) |
| Weight & dimensions | |
|---|---|
| Height | 35 mm |
| Depth | 170 mm |
| Width | 170 mm |
| Packaging content | |
|---|---|
| Bundled software | Norton® Internet Security (OEM version), Realtek® 8118 Gaming LAN Bandwidth Control Utility |
| Batteries included | Yes |
| Technical details | |
|---|---|
| Warranty period | 3 year(s) |
