Synology RX1217/192TB-HAT5300 12-Bay Rack (2U) Disk Array | HDD & SSD, Hot-Swap, Black, 12 drives installed
KEY FEATURES
- Home & Home Office
- Rack (2U) Black
- HDD Storage drives installed
- Hot-swap drive bays
- 500 W
100% Safe & Secure Checkout
Reviews
Frequently Asked Questions
Synology RX1217/192TB-HAT5300 12-Bay Rack (2U) Disk Array | HDD & SSD, Hot-Swap, Black, 12 drives installed
Description
Synology RX1217/192TB-HAT5300. Installed storage drive type: HDD, Storage drive interface: Serial ATA III, Storage drive size: 2.5/3.5". Chassis type: Rack (2U). Device class: Home & Home Office. Number of storage drives supported: 12, Supported storage drive types: HDD & SSD, Supported storage drive interfaces: Serial ATA II. Width: 430.5 mm, Depth: 664 mm, Height: 88 mm, Weight: 12.7 kg. Product colour: Black
Synology gives you the flexibility to start with a smaller storage capacity and expand as your business starts to grow. RX1217 and RX1217RP are 12-bay storage expansion units designed to provide seamless capacity expansion for select Synology RackStations.
Volume expansion & backup
When drive capacity is running low on a Synology RackStation, Synology RX1217/RX1217RP offers an easy way to immediately expand storage by providing 12 additional drive slots. The RAID volume on the Synology RackStation can be expanded directly without having to reformat the existing hard drives, ensuring service continuity during the expansion process. To ensure 24/7 service uptime, Synology RX1217RP is equipped with redundant power supplies, allowing automatic failover support if one of the PSUs fail.
When created as a separate volume, Synology RX1217/RX1217RP also serves as an additional local backup destination for Synology RackStations.
Reliable plug-and-use design
Synology RX1217/RX1217RP securely connects to Synology RackStation servers with a high-bandwidth expansion cable, ensuring maximum data throughput and smooth operation — as if they are part of the internal drives of Synology RackStation. SATA 6Gb/s interface ensures the installed drives provide high quality, outstanding data processing performance.
Green & easy to manage
Hibernation mode can be manually configured to start automatically when the system has been inactive for a period of time. This not only saves energy but also extends the lifespan of hard drives. RX1217/RX1217RP will also smartly power on/off with the attached RackStation, so no user intervention is needed to keep this system running smartly and efficiently.
Feature
Easy 14 days Returns
Eligible for Next day Delivery
100% Money-back guarantee
24/7 Customer support
Secure payment method
Shipping Information
- Next Business Day: £6.99
- 2 days Delivery: £4.99
- 3- 5 Days Shipping: £3.99
- Orders Over £99.00: Free Standard Delivery
| Storage | |
|---|---|
| Hot-swap drive bays | Yes |
| Data transfer rate | 6 Gbit/s |
| Supported storage drive interfaces | Serial ATA II |
| Storage drive size | 2.5/3.5" |
| Storage drive interface | Serial ATA III |
| Number of storage drives supported | 12 |
| Supported storage drive types | HDD & SSD |
| Number of storage drives installed | 12 |
| Installed storage drive type | HDD |
| Storage drives installed | Yes |
| Ports & interfaces | |
|---|---|
| InfiniBand | Yes |
| USB connectivity | No |
| Design | |
|---|---|
| Number of fans | 3 fan(s) |
| Noise level | 54.6 dB |
| Product colour | Black |
| Chassis type | Rack (2U) |
| Performance | |
|---|---|
| Compatible products | Synology RS4017xs+, RS3617xs+, RS3614xs+, RS3413xs+, RS3617xs, RS3617RPxs, RS3614(RP)xs, RS3412(RP)xs, RS3411(RP)xs, RS2416(RP)+, RS2414(RP)+, RS2212(RP)+, RS2211(RP)+ |
| Device class | Home & Home Office |
| Power | |
|---|---|
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100-240 V |
| Number of power supply units | 1 |
| Power supply unit (PSU) capacity | 500 W |
| Weight & dimensions | |
|---|---|
| Weight | 12.7 kg |
| Height | 88 mm |
| Depth | 664 mm |
| Width | 430.5 mm |
| Technical details | |
|---|---|
| Compliance certificates | RoHS |
| Harmonized System (HS) code | 84717020 |
| Packaging content | |
|---|---|
| Cables included | AC, InfiniBand |
| Operational conditions | |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 5 - 35 °C |
